Unmatched Protection: Hochiki Ekho EK-WL8-OV Hybrid Wireless Optical Smoke Sensor
Harness the power of innovation and industry-leading technology with the Hochiki Ekho EK-WL8-OV Hybrid Wireless Optical Smoke Sensor. Equipped with a built-in voice alarm and VAD, this cutting-edge sensor offers unrivaled fire detection capabilities, ensuring you and your loved ones are always safe.
A New Age of Fire Detection:
As a part of Hochiki's innovative Ekho family of products, the EK-WL8-OV promises to deliver exceptional reliability and performance.
This next-generation hybrid wireless fire detection system smoothly integrates with Hochiki’s respected ESP intelligent hardwired system[1], creating a seamlessly interconnected safety network for your home or business.
Superior Performance, Unrivaled Reliability
The EK-WL8-OV is more than just a smoke sensor. Leveraging optical smoke detection technologies and well-proven adaptive radio signal processing algorithms, this device significantly reduces the frequency of unwanted alarms[2].
Experience the highest levels of life safety and system reliability with this sophisticated sensor, that continuously adapts to changing operating conditions.
Advanced Features for a Secure Environment
This sensor doesn't stop at smoke detection. Equipped with a built-in voice sounder and visual alarm device (VAD) with white LEDs and 0.5 Hz flash rate, the EK-WL8-OV ensures that you're alerted immediately in case of fire incidents.
Prepare for an exceptional, all-encompassing safety system that leaves no room for error.
Get in contact with our expert sales team for queries or questions on this products - sales@firetradesupplies.com
| Feature | Specification |
|---|---|
| Product Code | EK-WL8-SND |
| Operating Frequency Range | 865 MHz |
| Communication Range (Open Air) | ≤ 1200 m |
| Modulation Type | Gaussian Frequency Shift Keying |
| Operating Frequency Channels | 6 |
| Max. Radiated Power | ≤ 25 mW |
| Wireless Signal Transmission | Every 2 minutes |
| Number of Tones | 4 (set via DIL switch) |
| Max. Sounder Output | 93 dB(A) at 1 meter |
| Max. Tolerated Humidity | 95% RH (non condensing) |
| Operating Temperature Range | -10 °C to + 55 °C |
| Dimensions | H 90 x W 90 x D 97 mm |
| Primary Power Supply | 3V lithium battery (CR123A) |
| Primary Battery Capacity | 1.2 Ahr |
| Primary Battery Life | Up to 10 years* |
| Secondary Power Supply | 3V lithium battery (CR123A) |
| Secondary Battery Capacity | 1.2 Ahr |
| Secondary Battery Life | 8 months |
