The HCP-DPS incorporates a red LED mounted on the front cover,
which can be selected as pulsing/non-pulsing for communications polling
and it is continuously lit when the HCP-DPS is operated.
The unit is operated by pressing the EN54 compliant non-frangible (plastic) element and,
once operated, produces a high level interupt, allowing the control panel to respond very quickly.
A built in test function initiated by the control panel ensures the integrity
of the device at all times and the device can be tested by insertion of a test key in the underside of the unit.
Two terminal blocks are provided for easy connection to the loop wiring.
The unit is addressed using the TCH-B100 Hand Held Programmer for quick and
reliable addressing and the unit can also be flush mounted if required.
An optional glass element is also available.
Incorportes a 'C Form' change over contact.
Addressed with TCH-B100 Hand Held Programmer
Surface or flush mounting
Incorporates a change over 'C Form' contact
