55000-062APO Conventional Exd Flame Detector (IR3) - Flameproof [SIL2]

ApolloSKU: 55000-062APO

Price:
Sale price$3,358.00 USD

Description

55000-062APO Conventional Exd Flame Detector (IR3) - Flameproof [SIL2]

The Conventional Exd Flame Detector (IR3) is designed for use in hazardous environments in indoor and outdoor applications. It is sensitive to low-frequency flickering infra-red radiation emitted by flames during combustion. The sensor operates even through a layer of oil, dust, water vapour or ice. BASEEFA has certified the detector for compliance to standards EN 60079-0, EN 60079-1 and EN 61241-1.

 Key Features:

  • ATEX & IECEx certified: II2GD Ex d IIC T4 Gb Ex tb IIICT135 °C Db IP66 A21 (Zones 1, 21, 2 and 22)
  • Selectable output options: Conventional two-wire, 4-20mA, Latching or Non-latching, Relay Contacts - Fire/Fault, Pre alarm
  • Class 1 sensitivity to EN 54-10 detects 0.1m2 fire at 25m
  • High optical interference immunity
  • Selectable response speed
  • Optical self test
  • Low power consumption
