Description
HCP-E/Y(SCI) Addressable Call Point with SCI (Yellow)
Manufactured by Hochiki, this Hochiki HCP-E/Y (SCI) Addressable Call Point With SCI (Yellow) is a Manual Call Point, which is fully compatible with Hochiki’s ESP analogue addressable protocol. The HCP-E/Y(SCI) incorporates a red LED mounted on the front cover, which can be selected as pulsing/non-pulsing for communications polling and is continuously lit when the HCP-E/Y(SCI) is operated.
The unit is operated by pressing the EN54 compliant non-frangible (plastic) element and, once operated, produces a high level ESP interrupt, allowing the control panel to respond very quickly. A built in test function initiated by the control panel ensures the integrity of the device at all times and the device can be tested by insertion of a test key in the underside of the unit. Two terminal blocks are provided for easy connection to the loop wiring.
The unit is addressed using the TCH-B200 Hand Held Programmer for quick and reliable addressing. The unit can be flush mounted as supplied. For surface fixing a suitable back box such as the SR MOUNTING BOX is required.
Details
Manufacturer: Hochiki
Part Number: HCP-E/Y (SCI)
Features
- Fast response Status LED
- Non-frangible element fitted as standard (conforms to EN54)
- Addressed with TCH-B200 Hand Held Programmer
- Surface or flush mounting (if surface mounting, requires SR MOUNTING BOX, sold separately)
